5 MP CMOS image sensor

2560 (H) × 1944 (V)

Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR

PAL: 1/25 s to 1/50,000 s,NTSC: 1/30 s to 1/50,000 s

ICR

Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360°

PAL/NTSC

2.4 mm, 2.8 mm, 3.6 mm, 6 mm fixed lens

2.4 mm, horizontal FOV: 110°, vertical FOV: 81°, diagonal FOV:137°

M12

Brightness, Sharpness, 3D DNR, Mirror, Smart IR

TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps,AHD: 5M@20fps, 4M@30fps, 4M@25fps,CVI: 4M@30fps, 4M@25fps,CVBS: PAL/NTSC

Auto/Color/BW (Black and White)

Digital WDR

BLC, HLC

Yes

Auto/Manual

Yes

Switchable TVI/AHD/CVI/CVBS

Plastic

Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11"

Approx. 143 g (0.32 lb.

-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)

HIKVISION-C

English

12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.

Max. 4.3 W

Up to 20 m

IP67
